TAC DuraDrive Electric Direct Mount Damper Actuator w/Manual Override MA41-7150

MA41-715X TAC DuraDrive Electric Direct Mount Damper Actuator w/Manual Override

$305.62 – $436.40

MA41-7150Two Pos SR 120V 133 lb-in$331.15
MA41-7150-502MA41-7150 w/ 2 SPDT Aux Switches$436.40
MA41-7151Two Pos SR 230V 133 lb-in$377.55
MA41-7151-502MA41-7151 w/ 2 SPDT Aux Switches$414.45
MA41-7153Two Pos ST 24V 133 lb-in$305.62
MA41-7153-502MA41-7153 w/ 2 SPDT Aux Switches$347.45
Categories: ,

Description

Specifications:For spring return applications that require two-position control of dampers and valves in HVAC system.

  • Spring Return
  • Two Position Actuator
  • Manual Override

Features:

  • 133 lb.-in. (4 N-m)
  • On-Off Control
  • Rugged die cast housngs
  • Overload protection throughout rotation
  • Optional built-in auxillary switch to provide for interfacing or signaling (-501 after model number)
  • Provides 95° rotation
  • Visual positon indicator provided
  • Rotation limiting available

Download Product Spec Sheet
